Standards
UNE 211025 (Construction and tests)
Low Voltage Directive: 2014/35/UE
CPR Regulation Nº 305/2011/UE:
Reaction to fire (Cca-s1b,d1,a1)
Additional performance in case of fire (if the CPR is not applicable):
IEC 60332-1-2, IEC 60332-3-24, IEC 60754-1 & 2 e IEC 61034-2.
Fire resistance: PH120
EN 50200 & IEC 60331-2
RoHS compliant.
Quality certificate
Technical characteristics & performances
-
Multicore
-
Bunched conductor (class 5) mm2
-
Maximum service temperature: 90ºC / 250ºC
-
300 / 500 V C.A.
-
Easier pulling
-
Easy peeling / easy strip
-
Easy installation
-
Protection against Electromagnetic disturbances
Fire performance
-
Fire resistance
-
Cca-s1b,d1,a1 (reaction to fire)
-
Fire retardant
-
Low heat emission
-
Low production of flaming droplets
-
Low opacity & production of smoke
-
Low acidity & conductivity of the gases: pH<4,3 2,5 µS/mm
-
Halogen free
-
Low emission of toxic gases
Uses and applications
-
Safety installations in case of fire
-
Buildings receiving the public
-
Industral use
-
Indoor use
Packaging
-
Coil
-
Drum
Functional features
-
Technical designation:
SOZ1-K (AS+) 300/500 V PH120
-
Constructive description:
Shielded multicore cable with intrinsic resistance to fire (AS+), halogen free.
CONSTRUCTION:
Conductor: Annealed copper, class 5 acc. to IEC 60228.
Insulation: Silicone.
Core identification: 2x - red and black.
Shield: Al/PET tape with a drain wire of tinned copper.
Shield coverage (100 %).
Oversheath: Thermoplastic polyolefin, LSZH. Color: red (or orange on request and MOQ).
Range: Multicore cable. Configurations: 2x1,5 mm2 & 2x2,5 mm2. -
Rated voltage:
300/500 V
-
Normal operation temperature:
90 ºC
-
Short-circuit temperature (5 s max):
250 ºC (t<5s)
-
Voltage test:
2 kV (15 min)
-
Colour:
Oversheath (red) / Core identification: 2x - red & black cores.
-
Fire performance:
Fire resistance: PH120 (EN 50200, IEC 60331-2)
Reaction to fire (CPR - EN 50575 & EN 13501-6): Cca-s1b,d1,a1.
Additional performance in case of fire (if the Construction Products Regulation is not applicable):
Fire resistant, fire & flame retardant, halogen-free and low gas and smoke emission with low opacity/toxicity/corrosivity/conductivity
(IEC 60332-1-2, IEC 60332-3-24, IEC 61034-2, IEC 60754-1 e IEC 60754-2). -
Type of installation:
Fixed
-
User´s guide:
Shielded cable with intrinsic resistance to fire, recommended for electrical circuits that require protection against disturbances and electromagnetic interference.
Specifically designed for use in security circuits associated with fire-fighting equipment, signaling, detection and alarm systems (pushbuttons, detectors...).
— Ambient operating temperature (ranges):
• Minimum: - 30 ºC (static – without exposure to movement, mechanical damages, shocks, or vibrations).
• Maximum: + 70 ºC.
• Minimum temperature for cable laying during installation and assembly of accessories: 0 ºC.
— Minimum bending radius: 10 x D. D = overall diameter of the cable in mm.
— Maximum pulling force:
• If the traction force is applied on the copper conductors: F = 50xS (N). "S" = cross sectional area of conductors (mm2).
• If the traction force is applied on the oversheath: F = 3xD2 (N). "D" = overall diameter of the cable (mm). -
Technical instructions:
.
-
Conductor:
Flexible
-
Halogen free:
Yes
-
Armoured cable:
No
